ART Mixer 3 kanaler (2 mic / 1 line) med USB interface

ART TUBEMIXCE Mixer 3 kanaler (2 mic / 1 line) med USB interface

ART Tube Mix tilbyder en kompakt, alsidig lyd-interface. Mixeren understøtter to mikrofon-inputs, et højimpedans instrument-input og to line-inputs samtidigt. Tube Mix kan også fungerer som en dual-channel tube mikrofon-forforstærker, eller stables og anvendes til instrument-input for ekstra varme og tone med guitar eller bas.

Alle input-kanaler er udstyret med 3-bånds EQ, to aux-sendere, panorering og level-kontrol. Udvalgte inputs inkluderer trim-kontrol og clip-indikatorer for optimal level-indstilling. Højimpedans instrument-input'et har også en amp-simulationsfunktion. Den alsidige output-sektion lader separate stereo monitor-mix på hovedbussen. En fleksibel Control-Room/Headphone-sektion kan overvåge hoved-mixet, USB-input'et og aux-senderen for maksimal fleksibilitet.

Fully Featured Tube Driven Five Channel Stereo USB Mixer
Two Wide Dynamic Range Low Noise Mic Preamp Channels
Dedicated High Impedance Instrument Input with Amp Simulator
Integrated 12AX7 Tube can be Applied to Either Microphone or Instrument Inputs
Switchable Low Noise +48V Phantom Power for Condenser Microphones
Precise VU Meters and Wide Range LED Meters with Selectable Source
Fully Featured Input Channels
Flexible Control Room / Monitor Section
USB 2.0 compliant. No special drivers needed with most modern versions of Windows, Mac OS, and Linux

Input Impedance: Microphone: 3.5k Ohm, Line (CH1, CH2, CH3/4), 10k Ohm, CH5 (Inst.), 1M Ohm
Output Impedance: Main, Control Room (Balanced/Unbalanced), 150/100 Ohm; , AUX Outputs, 150 Ohm, Headphones, 100 Ohm;
Frequency Response: 20-100kHz + 1dB
Maximum Input Level: CH1, CH2 (Mic), +9dBu, CH1 CH2 (Line In), +20dBu, CH3/4 (EQ Flat), +20dBu, CH5 (EQ Flat), +16dBu, AUX Return, +24dBu
Maximum Output Level: Main, Control Room (Balanced, Unbalanced), +20dBu/+17dBu, Aux Send, +20dBu, Headphones, 100mW / Ch @ 300 Ohm, 50mW /Ch @32 Ohm;
Maximum Gain: LINE IN to Main output (balanced), +63dB, CH 5 to Main output (balanced), 56dB, CH3/4 to Main output (balanced), +30dB
Equivalent Input Noise: Microphone (@max gain), 127dBu "C"wtd., Line (@max gain), -105dBu "C" wtd., Instrument (@ max gain), -112dBu "C" wtd.
USB Computer Interface: USB class compliant plug-and-play Mac and PC interface
A/D, D/A: 16 Bit, 44.1 kHz or 48 kHz, USB selectable from computer
Phantom Power: Switch selectable, +48V DC, filtered, current limited
Power Requirements: 18 VAC, 1000mA
Dimensions: 3.3"H x 7.8"W x 10.4"D (84mm x 198mm x 265mm)
Weight: 5.5 lbs (2.5 kg)
Note: 0 dBu = 0.775Vrms

Information

Type:	USB interface

Størrelse

Vægt:	2,5 kg
Bredde:	198 mm
Dybde:	265 mm
Højde:	84 mm
