TRK RPO1 USB Audiointerface 24-Bit 192 kHz

RCF TRK PRO1 audio interface pakke i et robust og gennemtænkt USB 2.0 studio-in-a-box med alle de nødvendige tilslutningsmuligheder for mikrofoner, musikinstrumenter eller line niveau signaler til en computer, der kører macOS eller Windows.
Det interne lineære forforstærkerkredsløb tillader tilslutning af 48V fantomdrevne mikrofoner og Hi-Z niveau instrumenter.
Indgangssignalet kan dirigeres til DAW (Digital Audio Workstation) med op til 24-bit, 192 kHz opløsning.
Interfacet kan tilsluttes en forstærker og højttalere, strømforsynede monitorer, hovedtelefoner, en analog mixer eller enhver anden analog lydenhed.

Software licens (gratis version) til Steinberg og Overloud - se mere på www.RCF.it

1 In 2 Out USB 2.0 Bus-Powered Audio Interface
Up to 24-Bit/192kHz
1 Mic and Instrument/line Combo input
High-quality preamp
Balanced Output
Independent headphone volume control
Robust Metal Case
Perfect for RDNet Measures
48V Phantom Power Supply
Independent Gain Control with Signal-Peak LED

MIC INPUT (Balanced)
Freq. Response: 20Hz-20kHz, +/-0.1 dB THD+N: Input Impedance: 3.5KOhm Gain Range: -9 dB ~ +47 dB Maximum Input Level: +9 dBu

LINE INPUT (Balanced)
Freq. Response: 20Hz-20kHz, +/-0.1dB THD+N Input Impedance: 15 kOhm Gain Range: -20 dB ~ +36 dB Maximum Input Level +20 dB

INSTRUMENT INPUT (Unbalanced)
Freq. Response: 20Hz-20kHz, +/-0.1 dB THD+N: 107dB (A-weighted) Input Impedance: 1MOhm Gain Range: -10 dB ~ +46 dB Maximum Input Level: +10 dBu

ANALOG OUTPUT (Balanced)
Maximum Output Level 0dBFS=12dBu Freq.Response: 20 Hz~20 kHz, +/-0.2 THD+N
HEADPHONES OUTPUT (Unbalanced)
Output Impedance:
SUPPORTED SAMPLE RATES 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
SUPPORTED BIT DEPTH 16 Bit, 24 Bit

PHYSICAL SPECIFICATIONS
Cabinet/Case Material: Steel
Color: Black - RAL 9005

SIZE
Height: 46 mm / 1.81 inches
Width: 91.4 mm / 3.6 inches
Depth: 125.8 mm / 4.95 inches
Weight: 0.5 kg / 1.1 lbs
